Coffee Science Lab

Extraction, roast, and cupping — measured, not guessed.

Meniscus runs the real SCA Golden Cup math, real roast development metrics, and the real 100-point cupping protocol — next to single-origin beans and the gear to brew them well.

Extraction yield target
18.0 – 22.0 %
Strength band
1.15 – 1.35 % TDS
Development time ratio
15 – 23 %
Lots on the bench
8 single origin

01Brewing control chart

Where each lot lands before you touch a kettle

A brew ratio is a line on this chart, not a point: because TDS = EY ÷ (ratio − retention), holding the ratio fixed and varying extraction traces a straight path through the strength/yield plane. Each line below is one of our lots at the ratio we ship with the bag, drawn with the standard 2.0 g/g retention assumption.

Read where a line crosses the Golden Cup box — that is the extraction window where that ratio hits the classic strength band. Our filter ratios run tighter than the 1:17–1:19 the SCA band assumes, so they cross it low and exit strong. That is a deliberate choice for single-cup brewing, and the chart shows it rather than hiding it.

  • Under-extracted — sour, thin, salty
  • Golden Cup — 18–22% EY, 1.15–1.35% TDS
  • Over-extracted — bitter, drying, hollow
Solve your own brew
Extraction yield % 14 → 26 Strength — % TDS 0.90 → 1.80

03Lot files

Three lots, opened up

Los Cristales Geisha 91.50SCA

Boquete · Panama

Los Cristales Geisha

Jasmine, mango, papaya, honeysuckle

Acidity 8
Sweetness 9
Body 4
Clarity 9
Balance 9
Altitude1,650 masl VarietyGeisha (Gesha)
Ratio1:16.5 Grind680 µm
Agtron71 DripperSolvent Hourglass

Washed, 48hr fermentation, raised-bed dried

El Mirador Pink Bourbon 89.50SCA

Huila · Colombia

El Mirador Pink Bourbon

Strawberry, cola, red grape, light funk

Acidity 8
Sweetness 8
Body 6
Clarity 7
Balance 7
Altitude1,900 masl VarietyPink Bourbon
Ratio1:16 Grind650 µm
Agtron66 DripperSolvent Conical 60

72hr anaerobic fermentation, washed, patio-dried

Kiaruthi Nyeri AA 89.00SCA

Nyeri · Kenya

Kiaruthi Nyeri AA

Blackcurrant, tomato leaf, winey acidity

Acidity 9
Sweetness 7
Body 6
Clarity 8
Balance 8
Altitude1,780 masl VarietySL-28, SL-34
Ratio1:15.5 Grind620 µm
Agtron64 DripperSolvent Wave

Washed, double fermentation, double wash, skin-dried on raised beds

04Roast ladder

Light to dark, by measurement

Ordered by Agtron Gourmet reading, lightest first. The swatch is an approximation of tile colour interpolated across the scale — it reads the roast, it does not replace a colorimeter.

05Lot index

Everything on the bench, in one sheet

Lot Origin Alt. Variety Agtron Ratio Grind K rel. Score
Los Cristales Geisha Boquete, Panama 1,650 Geisha (Gesha) 71 1:16.5 680 µm 1.28× 91.50
El Mirador Pink Bourbon Huila, Colombia 1,900 Pink Bourbon 66 1:16 650 µm 1.17× 89.50
Kiaruthi Nyeri AA Nyeri, Kenya 1,780 SL-28, SL-34 64 1:15.5 620 µm 1.07× 89.00
Werka Chelchele Yirgacheffe Yirgacheffe, Ethiopia 1,975 Heirloom Ethiopian landraces 68 1:16 650 µm 1.17× 88.25
Alto Roble Honey Tarrazú Tarrazú, Costa Rica 1,850 Caturra, Catuaí 60 1:15 600 µm 1.00× 86.75
El Cielo Antigua Antigua, Guatemala 1,700 Bourbon, Caturra 58 1:15 600 µm 1.00× 86.00
Boa Vista Natural Carmo de Minas, Brazil 1,250 Yellow Bourbon, Mundo Novo 55 1:14.5 580 µm 0.93× 84.50
Gunung Kerinci Wet-Hulled Kerinci Highlands, Indonesia 1,450 Tim Tim, Ateng 48 1:14 560 µm 0.87× 83.50

K rel. is bed permeability relative to a 600 µm reference grind, per the Kozeny–Carman d² relation. Higher means water moves through the bed faster at the same depth. Open the full archive

06Brew geometry

The bed shapes the cup

Solvent Conical 60

Geometry
60° single large-hole cone, spiral internal ribs
Material
glazed stoneware or hand-spun copper
Flow character
fast, high-control, pour-technique-dependent

Solvent Wave

Geometry
flat-bottom, 3 small holes, wave-shaped filter
Material
stainless steel or glazed stoneware
Flow character
even bed depth, forgiving of uneven pour

Solvent Facet

Geometry
dual-rib hybrid cone, adjustable flat/conical bed
Material
anodized aluminum
Flow character
tunable between fast-conical and slow-flat profiles

Solvent Hourglass

Geometry
hourglass carafe, thick bonded-paper filter
Material
borosilicate glass
Flow character
slow, heavy filtration, brighter and cleaner cup

Model a bed in the Dripper Lab

07Outfitter

Beans, drippers, and grinders

08Method

Why we publish the arithmetic

Most coffee sites ask you to trust a tasting note. We would rather hand you the control chart, the retention constant, and the grind our own brewers logged — then let you disagree with it on the evidence.

Every figure on this page is derived from published relations against the lot data we store: the Golden Cup solution for strength, the Kozeny–Carman square law for bed permeability, Development Time Ratio for roast, and the SCA 100-point protocol for the cup. Where a number is an approximation — the Agtron swatch colours, for instance — it is labelled as one.

Score a cupping Open the flavor wheel
